UTL 165 Watt Solar Panel 2Nos - 12V Poly Solar Panel with 25 Years Warranty

This 165 watt solar panel is a high efficiency polycrystalline solar panel with 36 cells and 5 busbars solar panel, mounted in an anodized aluminum alloy frame. Its power generating capacity is 8.5 amps current at peak. It is the highest capacity solar module in 12V capacity. It is also covered with 3.2mm toughened textured glass for a long life. UTL solar panels are the latest technology and most innovative solar panels. UTL solar panels are next-generation solar panels, manufactured by using premium quality A-grade solar cells.



TECHNICAL SPECIFICATION:-

Solar Panel Rating:-  165 Watt

Short circuit current:- 8.9 ampere

Operating voltage at Pmax VMP:- 18.9 volt

Operating current Imp:- 8.6 ampere

Open circuit voltage VOC:- 21.8 volt

Module efficiency:- 16.9%

Maximum system voltage:- 1000 volt

DESCRIPTION:-

Panel Type:- Polycrystalline

No. of Busbar:- 5BB.

No. of cells:- 36No.

Cell Type:- A-Grade

Module dimension:- 1486*666*35 mm

Weight:- 12Kg

junction box:- IP65

Warranty:- 25 Years Performance & 10 Year Product Warranty



Download Data Sheet.
